Sound Source Measurement / Localization Using Acoustic Camera + Anechoic Chamber
- HBK × SONORA Acoustic Measurement Solution Official Website
- Introduction to Our Solutions
- Sound Source Measurement / Localization Using Acoustic Camera + Anechoic Chamber
The HBK 9712-W-FEN Acoustic Camera is a sound source localization system that visually identifies the origin and intensity of sound. When used inside an anechoic chamber, it enables advanced measurements of sound sources placed in an environment free from sound reflections and external noise interference.
- Frequency Range (WA-1764-W-001): 140 Hz – 12 kHz
- SONAH: 140 Hz – 3 kHz
- Beamforming: 1 kHz – 12 kHz
- Microphones: 30 channels
- Supports two analysis methods: Beamforming and Holography
- Equipped with an intuitive GUI, the system enables quick identification of sound source locations, real-time analysis of sound images synchronized with video, and post-recording analysis of problem areas.
It also supports trigger-based measurements for capturing sporadic noise events. - Expandable to advanced analysis methods such as:
- Reference Signal Contribution Analysis
- Refined Beamforming
- Wideband Holography
Use Cases
- Sound Source Localization and Troubleshooting
- Detection and Recording of Abnormal Noises (BSR) Inside Vehicle Cabins
- High-Frequency Acoustic Leak Detection
- Proven Applications: Automobiles, Aircraft, Power Tools, Household Appliances, Wind Turbines, etc.
Specifications Table
Acoustic Measurement System
Features
Top Brands
We offer high-end solutions from two leading companies in the field of acoustic measurement instruments and acoustic testing environments: HBK and Sonora.
Total Solutions
With our proven expertise and extensive track record, we provide comprehensive solutions to address every challenge in acoustic measurement.
Complete Package
Moritani does more than just sell products — we provide full support from initial implementation to after-sales service, ensuring a seamless and reliable experience.
Sound Source Measurement / Localization Using Acoustic Camera + Anechoic Chamber Case Studies
Sound Source Measurement / Localization Using Acoustic Camera + Anechoic Chamber Case Studies
Brochure Download
Click here to download the brochure.
Contact Us
- Contact us by email
-
- Contact us by phone
-
Moritani Shokai
(Machinery Department No. 2, Tokyo Head Office)
Introduction of the Manufacturer
-
Hottinger Bruel & Kjaer
HHBK is a merger of two companies: Brüel & Kjær of Denmark and HBM of Germany.
Brüel & Kjær is one of the world’s leading manufacturers of acoustic and vibration measurement instruments, known as a total measurement chain supplier.Learn more about HBK
-
Sonora Technology Co., Ltd.
Sonora Technology is a leading Japanese manufacturer of industrial anechoic chambers and anechoic boxes.
From design and manufacturing to installation and acoustic performance assurance, Sonora provides fully integrated solutions to build complete acoustic measurement environments from the ground up.Learn more about Sonora
